XT
Sale Price
Price
€5.628,00
Regular price
Ready to obliterate all that comes before it, the Dreadnought XT is dripping in a wish list of fit-and-forget parts. The 170mm travel Fox 38 Grip2 forks are coupled to a custom-tuned Fox X2 Air shock, dishing out 154mm of superbly damped rear-wheel travel. The Trifecta high pivot suspension system boasts a square edge hit destroying 100% rearward wheel path that simultaneously eliminates unwanted and detrimental drivetrain forces. Often imitated but never equalled, our proven One Ride geometry not only delivers a consistent ride experience across the size spectrum but an unrivalled level of balance and composure that truly separates the Dreadnought from the competition. A bike that defies industry categorization, is equally at home in the Alpine, the bike park or between the tape, the Dreadnought XT will blur lines, exceed expectations and come back for more.
Please note: shipping, VAT and import duties calculated at checkout.
High Pivot Witchcraft
The most obvious feature of our Trifecta suspension system is the high pivot point and the resulting rearward axle path it produces. Unlike some other frame designs that talk of a rearward portion of their axle path, the height of our main pivot within the frame structure means our axle path takes a completely rearward trajectory throughout its travel. This rearward motion allows the rear wheel to move with, not against, any size of impact. This, in turn, allows the bike to remain composed and maintain momentum through rough terrain.
Dreadnought Geometry
| 170mm Fork | S | M | L | XL | |
|---|---|---|---|---|---|
| A | Reach | 440 | 462 | 484 | 506 |
| B | Stack | 612 | 621 | 630 | 639 |
| C | Hori. Top Tube Length | 593 | 617 | 641 | 665 |
| D | Seat Tube Length | 400 | 420 | 450 | 490 |
| E | Seat Tube Angle (Effective) | 76 | 76 | 76 | 76 |
| F | Seat Tube Angle (Actual) | 73.0 | 74.7 | 76.1 | 77.1 |
| G | Head Tube Length | 90 | 100 | 110 | 120 |
| H | Head Tube Angle | 63.5 | 63.5 | 63.5 | 63.5 |
| I | Front Center | 781 | 808 | 834 | 861 |
| J | Rear Center | 422 | 436 | 450 | 464 |
| K | Wheel base | 1203 | 1244 | 1284 | 1325 |
| L | BB Drop | -26 | -26 | -26 | -26 |
| M | BB Height | 347 | 347 | 347 | 347 |
| N | Stand Over | 721 | 721 | 727 | 733 |
| O | Fork Length | 583.71 | 583.71 | 583.71 | 583.71 |
| P | Fork Offset | 44 | 44 | 44 | 44 |
Sizing Guide
